Model |
CO CM 3.5KW |
|
Rated power |
3500VA/3500W |
|
Input Voltage |
230VAC |
|
Input Selectable Voltage Range |
170-280VAC(for personal computers) |
|
Input Frequency Range |
50Hz/60Hz(Auto） |
|
Output AC Voltage Regulation(Batt.Mode) |
230VAC±5% |
|
Output Surge Power |
7000VA |
|
Output Efficiency（Peak）PV to INV |
97% |
|
OutputEfficiency（Peak）BAT to INV |
94% |
|
Output Transfer Time |
10ms（for personal computers） |
|
Output Wave form |
Pure Sine Wave |
|
Battery Voltage |
24VDC |
|
Floating Charge Voltage |
27VDC |
|
Overcharge Protection |
28.2VDC |
|
Max.AC Charge Current |
60A |
|
MAX.PV Array Power |
4000W |
|
MPPT Range@ Operating Voltage |
30-500VDC |
|
Maximum PV Array Open Circuit Voltage |
500VDC |
|
Max.Solar Charge Current |
100A |
|
Maximum Efficiency |
98% |
|
Dimension. D*W*H（mm） |
330*278*98MM |
|
Net Weight（kgs） |
4.4kg |
|
Communication Interface |
RS485/RS232（Standard） |
|
Humidity |
5% to 95% Relative Humidity（Non-condensing） |
|
Operating Temperature |
0℃ to 55℃ |
|
Storage Temperature |
15℃ to 60℃ |
