Product Features
Comprehensive Safety Guard
Complete electrical protection, wide ‑30℃~60℃ operating temperature
Remote Smart Communication
Supports EMS remote monitoring, parameter setting, and working mode control
Strong Load Compatibility
Dual 30kW PV MPPT inputs for on‑grid/off‑grid switching
Expandable Battery Module
7‑pack 51.2V LFP battery assembly supplies 112kWh usable energy with flexible stacked capacity‑expansion design
Battery Module Type
51.2V
Battery Module Number
7
Battery System Voltage
358.4V
Battery Capacity
314Ah
Normal Energy
112kWh
Battery Max Charge Current
200A
Charge Voltage
386.4V
Cut‑off Voltage
313.6V
Reliable All‑in‑one Cabinet‑type Energy Storage System
Capable of stable on‑grid & off‑grid power output. Equipped with comprehensive safety safeguards and intelligent remote‑management function, perfectly catering to commercial, industrial and large‑scale renewable‑energy storage demands.
Industrial‑Grade Integrated Energy‑storage Cabinet
Hybrid on/off‑grid working modes, high load adaptability and multi‑protection design. Well‑equipped to handle factory power‑backup, load regulation and outdoor harsh‑condition deployment.
